Product Description

Jabsco Par-Max 4.0 Freshwater Pressure Pump – Q401J-118S-3A

The heavy duty Par-max 4.0 freshwater pressure pump offers robust construction and high performance. With a heavy duty wider diameter motor and a powder coated shell, cast aluminum end bells and lower housing – to improve pressure capability and offer longer life and exceptional performance.

This ideal robust heavy duty pump provides freshwater automatically to up to 4 outlets on pleasure craft up to approx. the 13metre (40 Ft) range.

The heavy-duty quad chamber automatic pressure pump gives flow up to 4 US Gallons per minute (15.2 litres per minute) and pressure up to 40 PSI and can serve up to 4 x 12mm outlets including galley, shower and additional faucet. The Par-Max 4.0 HD gives very smooth water flow even at low demand due to its built-in pulsation dampening by-pass valve which controls unwanted cycling and reduces noise

• Fully automatic operation with built-in pressure switch
• Pressure switch 60PSI
• Up to 15.2litres 4 US gallons per minute flow
• Serves up to 4 x 12mm (1/2) outlets on board simultaneously
• Modern 4 chamber design gives smooth flow and quiet operation
• Built-in internal by-pass lowers water pulsation
• Self primes to 2.4metres (8 feet)
• Can be installed vertically or horizontally
• Can be run dry for short periods without damage
• Powerful heavy duty ignition protected motor with thermal protection TCO
• Vibration dampening base plate & feet for quiet efficient operation
• Available in both 12 volt & 24 volt in both 40PSI & 60PSI versions

Included:

• Inlet filter
• Corrosion resistant motor
• Soft rubber vibration dampening mounts
• 2 x 12m barbed quick connect plug-in hose ports

Spare Parts Available:

J21-119 Replacement plug-In 40 mesh inlet strainer Jabsco 46400-0030

J25-171 Replacement port clips (pair) Jabsco 30647-1000

J25-209 Replacement 40 PSI pressure switch kit Jabsco 16470-0040

J25-210 Replacement 60 PSI pressure switch kit Jabsco 16470-0060

J25-212 Check valve & housing assembly kit Jabsco 18753-0731

J25-213 Diaphragm & drive assembly kit Jabsco 18753-0730
