Product Description

JABSCO ELECTRIC TOILET – QUIET FLUSH STANDARD BOWL 24VOLT – 37245-3094

The Jabsco quiet flush system is an electric toilet system that has been designed to dramatically reduce the noise level of the flush pump to make life onboard so much more comfortable. Even for those sleeping off watch!

Salt Water Intake

Uses a very quiet electric Par-Max 4 diaphragm pump to draw salt water into the toilet for flushing and rinsing the bowl. The pump can be remotely mounted in a convenient position. It replaces the noisy impeller driven flush pump that is normally housed in the base of the electric toilet.

Fresh Water Intake

Uses the boats existing fresh water pressure pump, which must be capable of a flow rate of 13.5 litres per minute or more. The fresh water kit includes a solenoid valve and siphon breaker assembly to prevent any backflow form the toilet to the fresh water system. Fresh water flush systems are much cleaner and carry less odour then salt water flush systems. Fresh water flush is more ideal, as long as your fresh water pump is large enough and your fresh water tanks are large enough to accommodate the additional usage.

• Powerful macerator discharge pump that breaks up waste and evacuates the toilet
• Modern 3 way control panel that allows you to select normal flush and drain cycle or raise or lower the water level
• 2 metres of white hose to connect to either the solenoid valve or salt water intake pump
• Connections for 20mm (3/4inch) intake hose and both 25mm (1inch) or 38mm (1 1/2inch) outlet hose

Size: 350mm wide x 450mm deep x 350mm high

Also available:

J10-121 Toilet – Quiet Flush Standard Bowl 12v Fresh Water

J10-123Toilet – Quiet Flush Large Bowl 12v Fresh Water

J10-125 Toilet –Quiet Flush Standard Bowl 12v Salt Water

J10-127 Toilet – Quiet Flush Large Bowl 12v Salt Water

J10-128 Toilet – Quiet Flush Large Bowl 24v Salt Water
